Q-Link Module

Q Link
Introducing Feniex Q-Link, the innovative serial device to connect all of your Q Serial lightheads. Specially engineered for use with Feniex’s state-of-the-art serial technology, connect up to 48 lightheads using only one Q-Link device.
Our Q-Link device uses Q Serial Zoning Technology to make programming your build easier than ever before. No need to tap mode wires, simply connect your Q Serial lightheads to your Q-Link device using the 2 serial wires and the Q-Link Software. Then, set each Q Serial lighthead into your desired zones with a touch of the zoning magnet. Within moments, your zones are set and you can program any function and color using our intuitive Q-Link Software. Detailed walkthrough videos are available on Feniex University.
FEATURES
Zoning magnet included
27 programmable inputs
Includes 8 serial ports
Each serial port supports up to 6 Q Serial lightheads
Syncs up to 48 lightheads using one Q Link device
Comes with unlimited use of Feniex’s Q Link Software
Over 20 programmable flash patterns
Available functions include Flood, Cruise, and Stop Tail Turn and more
SAE J1113-11 Certified


SPECIFICATIONS
 Current Draw: 1 Amp
 Cable Length: 1 Foot
 Input Voltage: 10-18 VDC
 Dim: 3.95" x 2.6" x .75"
 2 Year Manufacturer Warranty
 Made in the USA: Austin, TX
